An insulin pump is a medical device designed to deliver insulin continuously or intermittently to individuals with diabetes, allowing for more precise blood sugar management compared to traditional methods such as multiple daily injections. These compact and portable devices can be worn on the body, typically connected to an infusion set that delivers insulin subcutaneously. As technology advances, pumps are becoming more integrated with continuous glucose monitoring systems, enabling automated insulin delivery based on real-time blood sugar readings. This trend has led to a growing demand for high-performance, reliable, and compact rechargeable batteries. These batteries need to have a long lifespan, quick charging times, and the ability to withstand frequent charge-discharge cycles. As the market for insulin pumps continues to expand, so too does the demand for advanced rechargeable battery technology.
Rechargeable batteries play a crucial role in the operation of insulin pumps, which are essential devices for managing diabetes by delivering insulin continuously or as needed. Insulin pumps require reliable and efficient power sources to ensure consistent insulin delivery. Rechargeable batteries have significantly enhanced the convenience and reliability of insulin pumps. By eliminating the need for frequent battery replacements, they offer a more user-friendly and sustainable solution for people with diabetes.The specific type of rechargeable battery commonly used in these devices is the Li-ion or Lithium Polymer (LiPo) battery.
●Longer Lifespan: LiPo batteries can last longer than traditional nickel-cadmium (NiCad) batteries, reducing the frequency of replacements.
●High Energy Density: They provide more power in a smaller package, which is essential for the compact design of insulin pumps. Rechargeable batteries allow for compact, user-friendly devices that are easy to wear and carry, a critical feature in medical devices worn on the body.
●Cost-Effective: Rechargeable batteries help reduce the ongoing costs associated with replacing disposable batteries, which is particularly advantageous for users with long-term treatment needs.
●Temperature Resilience: LiPo batteries perform well in colder conditions, ensuring that insulin delivery is not compromised by environmental factors.
●Rechargeable Lithium-Ion Coin Cell (Custom options: diameter ≥7.8mm; height ≥1.5mm)
●Shaped Pouch Lipo Battery Cell (Custom options: width ≥4.1mm; height ≥0.5mm)
●Shaped Metal Casing Lipo Battery Cell (Custom options: width ≥6mm; height ≥3.5mm)
Rechargeable Lithium-Ion Coin Cell
Shaped Pouch Lipo Battery Cell
Shaped Metal Casing Lipo Battery Cell
Grepow has provided dedicated energy solutions for high-tech applications in
bluetooth headsets for smart phones, notebook bridging function, body shaping
and training sensors, medical and health care equipment, wireless sensor and
network infrastructure and many more. For all these applications, Grepow offers
a range of rechargeable Lithium-Ion button cells and battery assemblies in
diameters from 7.8 - 24 mm with 6.5 mAh to 210 mAh.
PN. | Nominal Voltage | C rate | Capacity | Weigh | Diameter | Thickness |
3.7/3.8/3.9V | 1C | 24/28/30/31mAh | 0.7/0.75±0.1g | 7.8mm | 5.4mm | |
3.85V | 1C | 38mAh | 0.95±0.1g | 9.5mm | 5mm | |
3.7/3.8/3.9V | 1C/5C | 41/46/49/52/55mAh | 1.1/1.3±0.1g | 10mm | 5.4mm | |
3.7/3.8/3.9V | 1C/5C | 18/20mAh | 0.9±0.1g | 12mm | 2.4mm | |
3.7V | 1C | 50mAh | 1.4±0.15g | 12mm | 4mm | |
3.85V | 1C | 68mAh | 1.65±0.15g | 12mm | 5mm | |
3.7/3.8/3.9V | 1C/5C | 68/70/75/77/87mAh | 1.8±0.1g | 12mm | 5.4mm |
Grepow offers a range of shaped pouch batteries that are perfectly suited to various terminal device shapes. We provide custom shaped Lithium-Ion pouch batteries as thin as 0.5mm and as narrow as 4.1mm. Available shapes include cruved, round, L-shaped, D-shaped, and C-shaped, ect. Grepow's shaped pouch batteries boast excellent performance and a cycle life of over 1000 cycles, operating within a temperature range of -50°C to 50°C / -40°C to 60°C, and can achieve fast charging at up to 5C.
Model NO. | Full-Charged Voltage | Capacity | Thickness | Width | Length |
4.2/4.35V | 7.5-140mAh | 0.5-0.85mm | 15-49mm | 34.3-55.5mm | |
4.2/4.35/4.4V | 13-430mAh | 1.6-7.87mm | 6.5-11mm | 13-60.8mm | |
4.2/4.35/4.4V | 62-2120mAh | 7.5-2.3mm | 12-64.7mm | 15.5-54.64mm | |
4.2/4.35/4.4/4.45/4.8V | 7.5-4200mAh | 0.5-11.8mm | 6.5-50mm | 12-88.5mm | |
4.2V | 605mAh | 4.58mm | 18.9mm | 71.95mm |
Grepow offers a diverse range of rechargeable metal casing shaped batteries to meet various application needs. Unlike pouch-shaped batteries, metal casing batteries provide enhanced safety by effectively preventing the risk of battery swelling. This advantage eliminates the need for additional design space to accommodate potential expansion, enabling more efficient use of available space. Consequently, these batteries are ideally suited for products with stringent space requirements, ensuring optimal compatibility with compact and demanding design specifications.
PN. | Nominal Voltage | C rate | Capacity | Weigh | Size (H*W*L) |
3.85V | 1C | 18mAh | 0.55g | 4.0*6*9mm | |
3.85V | 1C | 20mAh | 0.63g | 4.3*6*10mm | |
3.85V | 1C | 105mAh | 3.3g | 3.2*17*24mm | |
3.85V | 1C | 255mAh | 6.5g | 3.3*24*24mm | |
3.85V | 1C | 320mAh | 7.65g | 4.5*19*27mm | |
3.85V | 1C | 1200mAh | 20.3g | 8*34*42mm | |
3.85V | 1C | 1200mAh | 19.5g | 5.6*30*50mm |
