Model NO. | C-Rate | Nom. Voltage | Capacity | Max Cont. Discharge Current | Thickness (mm) | Width (mm) | Length (mm) | Weight (g) |
GRP5017095 | 15C | 3.8V | 750mAh | 11.25A | 4.8±0.2 | 17.0±1.0 | 96.0±1.0 | 14.5±1.5 |
GRP7027080 | 15C | 3.8V | 1600mAh | 16A | 6.7±0.3 | 26.5±1.0 | 81.0±1.0 | 30.0±1.5 |
GRP6642085 | 15C | 3.8V | 2800mAh | 42A | 6.3±0.2 | 42±1.0 | 86.5±1.0 | 48.0±2.0 |
GRP5843084 | 15C | 3.8V | 3000mAh | 20A | 5.3±0.2 | 42.5±1.0 | 84±1.0 | 46.0±2.0 |
GRP7942080 | 15C | 3.8V | 3600mAh | 20A | 7.5±0.3 | 41.0±1.0 | 80.5±1.0 | 58.0±2.0 |
GRP7842080 | 15C | 3.8V | 3850mAh | 20A | 7.5±0.3 | 41.5±1.0 | 80±1.0 | 59.0±2.0 |
GRP5267103 | 15C | 3.8V | 4000mAh | 60A | 4.9±0.2 | 66±1.0 | 102.5±1.0 | 73.0±2.0 |
GRP8143084 | 15C | 3.8V | 4200mAh | 20A | 7.7±0.3 | 42.5±1.0 | 84.5±1.0 | 65.0±2.5 |
GRP8843084 | 15C | 3.8V | 4800mAh | 72A | 8.5±0.3 | 42.5±1.0 | 84.5±1.0 | 76.5±2.5 |
GRP6642124 | 15C | 3.8V | 5150mAh | 77.25A | 6.5±0.2 | 41.5±1.0 | 125.0±1.0 | 82.5±3.0 |
GRP9044124 | 15C | 3.8V | 5800mAh | 87A | 8.7±0.3 | 43±1.0 | 124.5±1.0 | 102.5±3.0 |
GRP8043143 | 15C | 3.8V | 6000mAh | 90A | 7.7±0.3 | 42.0±1.0 | 144.0±1.0 | 104.0±5.0 |
GRPB243084 | 15C | 3.8V | 6350mAh | 95.25A | 10.9±0.3 | 42.5±1.0 | 84.5±1.0 | 98.0±3.0 |
GRPA344124 | 15C | 3.8V | 6600mAh | 99A | 10.0±0.3 | 43±1.0 | 125±1.0 | 116.0±3.0 |
GRP6956155 | 15C | 3.8V | 7100mAh | 106.5A | 6.65±0.15 | 55.5±1.0 | 154.5±1.0 | 125.0±5.0 |
GRPB042126 | 15C | 3.8V | 7400mAh | 111A | 10.7±0.3 | 41.5±1.0 | 127±1.0 | 127.0±3.0 |
GRP9842124 | 15C | 3.8V | 7600mAh | 40A | 9.5±0.3 | 41.5±1.0 | 124.5±1.0 | 116.0±3.0 |
GRP6475140 | 15C | 3.8V | 7850mAh | 117.75A | 6.2±0.2 | 75.0±1.0 | 140.0±1.0 | 138.0±5.0 |
GRPA842124 | 15C | 3.8V | 8000mAh | 40A | 10.45±0.3 | 41.5±1.0 | 125±1.0 | 126.0±3.0 |
GRPA742124 | 15C | 3.8V | 8200mAh | 40A | 10.7±0.3 | 41.5±1.0 | 125±1.0 | 130.0±3.0 |
GRPB242126 | 15C | 3.8V | 9000mAh | 54A | 10.9±0.3 | 42.0±1.0 | 126.5±1.0 | 138.0±3.0 |
GRP8364159 | 15C | 3.8V | 10000mAh | 60A | 8.0±0.3 | 63.5±1.0 | 158.5±1.0 | 171.0±5.0 |
GRP9364159 | 15C | 3.8V | 11000mAh | 66A | 9.1±0.3 | 63.5±1.0 | 158.0±1.0 | 193.0±5.0 |
GRP9185155 | 15C | 3.8V | 13800mAh | 82.8A | 8.8±0.3 | 84.5±1.0 | 154.5±1.0 | 242.0±5.0 |
GRP9885155 | 15C | 3.8V | 15000mAh | 90A | 9.5±0.3 | 84.5±1.0 | 154.5±1.0 | 261.0±5.0 |
GRP9990190 | 15C | 3.8V | 21000mAh | 105A | 9.5±0.3 | 90.0±1.0 | 190.0±1.0 | 355.0±10.0 |
GRP8780266 | 15C | 3.8V | 24000mAh | 72A | 8.5±0.25 | 78.5±1.0 | 265.0±1.0 | 400.0±10.0 |
GRP94C0185 | 15C | 3.8V | 25800mAh | 129A | 9.1±0.3 | 119.5±1.0 | 184.5±1.0 | 445.0±10.0 |
● High energy density, longer battery life, up to 15% longer than ordinary batteries;
● The energy density of the battery is increased by about 15% under the same rate and size;
● Simulating the actual use of the reliability test, can meet the 3-year service life, to meet the demand of high and low temperature, different multiplier on power industry applications;
● High and stable discharge platform, frequent use does not affect the life of the battery;
● Multiplier cycle performance can maintain 80% of the original capacity after 300 cycles;
● Capable of mass production and good cell consistency
Grepow high-voltage lithium batteries have nominal voltages of 3.8V, 3.85V, 3.95V, corresponding to charge cut-off voltages of 4.35V, 4.4V and 4.45V respectively. compared with conventional ones, high-voltage batteries have high energy density and high discharge platform; under the same usage conditions, high-voltage batteries can discharge more capacity, so they have longer runtime and stronger power; Grepow high-voltage batteries range can be increased by 15%-25%, which is one of the core technologies of Grepow.
▶ Source manufacturer, physical factory, strong R&D production capacity, short delivery time and sufficient stock.
▶ Self-researched high-voltage lithium battery cells, sufficient capacity, refusal of false label, guaranteed capacity.
▶ Strict quality control: construct a full range of quality system from parts to finished products to ensure product quality
▶ Safe and reliable in line with a variety of domestic and international battery certification
▶ Perfect service system: Quickly reply to customer problems and provide solutions
▶ Provide local instant customer support in China, USA and Germany
● Flexible support for customized solutions
● Reliable and stable performance
● Samples and mass production available
● OEM, ODM available
