Model NO. | C-Rate | Nom. Voltage | Capacity | Max Cont. Discharge Current | Thickness (mm) | Width (mm) | Length (mm) | Weight (g) |
GRP5934050 | 10C | 3.8V | 1000mAh | 10A | 5.8±0.2 | 33±1.0 | 50±1.0 | 18.5±1.0 |
GRP7243058 | 10C | 3.8V | 2000mAh | 20A | 6.9±0.3 | 42.5±1.0 | 58.5±1.0 | 36.5±1.5 |
GRP5550077 | 10C | 3.8V | 2300mAh | 23A | 5.2±0.2 | 49.5±1.0 | 76.5±1.0 | 41.0±2.0 |
GRP6342083 | 10C | 3.8V | 3100mAh | 20A | 6.1±0.2 | 49.5±1.0 | 82±1.0 | 48.0±2.0 |
GRP6843084 | 10C | 3.8V | 3700mAh | 37A | 6.6±0.2 | 49.5±1.0 | 84.0±1.0 | 58.5±2.0 |
GRP9542080 | 10C | 3.8V | 4300mAh | 43A | 9.2±0.3 | 41±1.0 | 81±1.0 | 70.0±3.0 |
GRP6343135 | 10C | 3.8V | 4500mAh | 40A | 6.1±0.2 | 43.0±1.0 | 135.0±1.0 | 74.0±3.0 |
GRP6845135 | 10C | 3.8V | 5200mAh | 52A | 6.7±0.2 | 44.5±1.0 | 134.5±1.0 | 89.0±2.0 |
GRPA834124 | 10C | 3.8V | 5800mAh | 58A | 10.5±0.3 | 33.5±1.0 | 124±1.0 | 95.0±3.0 |
GRP7667096 | 10C | 3.8V | 6000mAh | 60A | 7.2±0.3 | 66.5±1.0 | 96.5±1.0 | 99.0±3.0 |
GRPA734124 | 10C | 3.8V | 6300mAh | 40A | 10.5±0.3 | 33.5±1.0 | 124±1.0 | 100.0±3.0 |
GRPB042126 | 10C | 3.8V | 7500mAh | 75A | 10.5±0.3 | 41.5±1.0 | 127±1.0 | 125.0±3.0 |
GRPA942126 | 10C | 3.8V | 8000mAh | 24A | 10.6±0.3 | 41.5±1.0 | 127±1.0 | 131.0±3.0 |
GRP7164155 | 10C | 3.8V | 8500mAh | 42.5A | 6.8±0.3 | 63.5±1.0 | 154.5±1.0 | 145.0±5.0 |
GRPA948142 | 10C | 3.8V | 9700mAh | 48.5A | 10.7±0.3 | 47±1.0 | 141.5±1.0 | 159.0±3.0 |
GRP9946170 | 10C | 3.8V | 10000mAh | 50A | 9.6±0.3 | 45.5±1.0 | 169±1.0 | 166.0±5.0 |
GRP8270175 | 10C | 3.8V | 12000mAh | 120A | 7.9±0.3 | 69.0±1.0 | 174.0±1.0 | 202.0±5.0 |
GRP8995132 | 10C | 3.8V | 14000mAh | 70A | 8.6±0.3 | 94.5±1.0 | 131.0±1.0 | 232.0±5.0 |
GRPA275175 | 10C | 3.8V | 16800mAh | 50.4A | 9.8±0.3 | 74.5±1.0 | 174.5±1.0 | 276.0±5.0 |
GRP8295183 | 10C | 3.8V | 18000mAh | 54A | 8.0±0.3 | 94.0±1.0 | 182.0±1.0 | 299.0±5.0 |
GRP9990190 | 10C | 3.8V | 22000mAh | 66A | 9.6±0.3 | 89.5±1.0 | 189.5±1.0 | 351.0±10.0 |
GRPA690190 | 10C | 3.8V | 24300mAh | 72.9A | 10.3±0.3 | 89.5±1.0 | 189.5±1.0 | 382.0±10.0 |
GRPA5B0194 | 10C | 3.8V | 27500mAh | 82.5A | 10.2±0.3 | 110.0±1.0 | 194.0±1.0 | 442.0±10.0 |
GRPA0B1220 | 10C | 3.8V | 30000mAh | 90A | 9.7±0.3 | 110.5±1.0 | 220.0±1.0 | 492.0±10.0 |
GRPA0C0200 | 10C | 3.8V | 32000mAh | 96A | 9.7±0.3 | 119.5±1.0 | 199.5±1.0 | 505.0±10.0 |
GRPA5A0260 | 10C | 3.8V | 34000mAh | 102A | 10.1±0.3 | 99.0±1.0 | 260.0±1.0 | 568.0±10.0 |
GRP95B0270 | 10C | 3.8V | 35800mAh | 107.4A | 9.2±0.3 | 110.0±1.0 | 270.0±1.0 | 576.0±10.0 |
GRPA7C0240 | 10C | 3.8V | 40000mAh | 120A | 10.4±0.3 | 119.5±1.0 | 239.5±1.0 | 655.0±10.0 |
● High energy density, longer battery life, up to 15% longer than ordinary batteries;
● The energy density of the battery is increased by about 15% under the same rate and size;
● Simulating the actual use of the reliability test, can meet the 3-year service life, to meet the demand of high and low temperature, different multiplier on power industry applications;
● High and stable discharge platform, frequent use does not affect the life of the battery;
● Multiplier cycle performance can maintain 80% of the original capacity after 300 cycles;
● Capable of mass production and good cell consistency
Grepow high-voltage lithium batteries have nominal voltages of 3.8V, 3.85V, 3.95V, corresponding to charge cut-off voltages of 4.35V, 4.4V and 4.45V respectively. compared with conventional ones, high-voltage batteries have high energy density and high discharge platform; under the same usage conditions, high-voltage batteries can discharge more capacity, so they have longer runtime and stronger power; Grepow high-voltage batteries range can be increased by 15%-25%, which is one of the core technologies of Grepow.
▶ Source manufacturer, physical factory, strong R&D production capacity, short delivery time and sufficient stock.
▶ Self-researched high-voltage lithium battery cells, sufficient capacity, refusal of false label, guaranteed capacity.
▶ Strict quality control: construct a full range of quality system from parts to finished products to ensure product quality
▶ Safe and reliable in line with a variety of domestic and international battery certification
▶ Perfect service system: Quickly reply to customer problems and provide solutions
▶ Provide local instant customer support in China, USA and Germany
● Flexible support for customized solutions
● Reliable and stable performance
● Samples and mass production available
● OEM, ODM available
