Model NO. | C-Rate | Nom. Voltage | Capacity | Max. Cont. Discharge Current | Thickness (mm) | Width (mm) | Length (mm) | Weight (g) |
GRP5464074 | 25C | 3.2V | 1700mAh | 42.5A | 5.2±0.2 | 63.5±1.0 | 73.5±1.0 | 46.5±2.0 |
GRP6445090 | 25C | 3.2V | 1900mAh | 47.5A | 6.2±0.2 | 44.5±1.0 | 90.5±1.0 | 49.5±2.0 |
GRP8734096 | 25C | 3.2V | 2100mAh | 52.5A | 8.4±0.3 | 33.5±1.0 | 96.5±1.0 | 52.5±2.0 |
GRP5954090 | 25C | 3.2V | 2100mAh | 52.5A | 5.7±0.2 | 53.5±1.0 | 91.0±1.0 | 55.0±2.0 |
GRP7146094 | 25C | 3.2V | 2300mAh | 57.5A | 6.8±0.3 | 45±1.0 | 94.5±1.0 | 58.0±2.0 |
GRP8348085 | 25C | 3.2V | 2500mAh | 62.5A | 8.0±0.3 | 47.5±1.0 | 85.5±1.0 | 63.0±2.0 |
GRP7360078 | 25C | 3.2V | 2500mAh | 62.5A | 7.1±0.3 | 59.5±1.0 | 79.0±1.0 | 63.0±2.5 |
GRP5961095 | 25C | 3.2V | 2550mAh | 63.75A | 5.7±0.2 | 60.5±1.0 | 96.0±1.0 | 66.5±2.5 |
GRP5970096 | 25C | 3.2V | 2800mAh | 70A | 5.6±0.2 | 69.5±1.0 | 96.5±1.0 | 73.0±2.0 |
GRP8442126 | 25C | 3.2V | 3500mAh | 87.5A | 8.1±0.3 | 41.5±1.0 | 127.0±1.0 | 89±3.0 |
GRP6460119 | 25C | 3.2V | 3500mAh | 87.5A | 6.3±0.2 | 59.5±1.0 | 119.0±1.0 | 90.0±3.0 |
GRP8061115 | 25C | 3.2V | 4350mAh | 108.75A | 7.7±0.3 | 60.5±1.0 | 115±1.0 | 109.0±3.0 |
GRP8561115 | 25C | 3.2V | 4600mAh | 115A | 8.2±0.3 | 60.5±1.0 | 115.5±1.0 | 118.0±3.0 |
GRP9161115 | 25C | 3.2V | 5000mAh | 125A | 8.8±0.3 | 60.5±1.0 | 115±1.0 | 128.0±3.0 |
GRP8798112 | 25C | 3.2V | 7200mAh | 180A | 8.4±0.3 | 98.0±1.0 | 113.0±1.0 | 185.0±5.0 |
GRP8678156 | 25C | 3.2V | 8000mAh | 80A | 8.2±0.3 | 77.5±1.0 | 153.5±1.0 | 199.0±3.0 |
GRP8578185 | 25C | 3.2V | 9600mAh | 160A | 8.2±0.3 | 77.5±1.0 | 184.5±1.0 | 243.0±5.0 |
● High performance in power, discharge, and life cycles due to stacking process.
● Ability to achieve 150C pulse, 90C discharge for 2 seconds, 45C continuous discharge, and 5C fast charging.
● Provides better temperature stability and tolerance due to the allowance of higher discharge rate.
● Ultra-thin characteristics, light weight, flexible size, flexible shapes, and ability to accommodate many applications.
Different C Rate Discharge Curve (Nominal Capacity: 1600mAh)
The testing battery nominal capacity is 1600mAh, from the discharge curve under different discharge C rate, we can find the 25C performance is the best, but from 30C to 40C discharge rate, the Grepow LiFePO4 high C rate battery still can provide more than 93% discharge efficiency. | Cycle Life Testing Curve (1C Charging)
Under charging at 1C and discharging at 25C, the high C rate LiFePO4 cell performs an outstanding cycle life performance. From the sheet, we can get there is more than 94% capacity retention rate after 300 cycles. |
Compared with high rate lithium polymer batteries, Grepow high rate lithium iron phosphate batteries use an innovative chemical formulation that provides safe and stable discharge performance; its cycle life is up to 2,000 cycles and can work normally in high temperature environments up to 60°C. Grepow provides integrated battery system customization service of high rate LiFePO4 battery cell customization + battery management system (BMS) + structure design. We can also customize high rate LiFePO4 batteries for different industries according to the actual needs of users, so that your products have greater competitive ability.
▶Battery is more environmental friendly;
▶Stable performance;
▶Safer chemical substance;
▶Support 25C multiplier continuous discharge;
▶Longer life span, more than 2000 cycles;
▶Can work normally in high temperature environment, can withstand 60℃;
▶Perfect service system: Quickly reply to customers' problems and provide solutions
▶Instant local customer support in China, USA, Germany
● Flexible support for customized solutions
● Reliable and stable performance
● Samples and mass production available
● OEM, ODM available
The high C rate LiFePO4 batteries developed and produced by GREPOW are widely used in emergency starter power, car jumper, ups, electric bone drill, electric forklift, electric go-kart, electric lift bed, electric paraglider, industrial robot, high performance racing car, sports equipment starter power, etc. Our R&D team works closely with our customers to provide the right solution for their battery applications.
