Model NO. | C-Rate | Nom. Voltage | Capacity | Max. Cont. Discharge Current | Thickness (mm) | Width (mm) | Length (mm) | Weight (g) |
GRP3730048 | 20C | 3.2V | 300mAh | 6A | 3.5±0.2 | 30±1.0 | 49±1.0 | 9.0±0.5 |
GRP5030060 | 20C | 3.2V | 600mAh | 12A | 4.9±0.2 | 29.5±1.0 | 61.5±1.0 | 15.5±1.5 |
GRP4635062 | 20C | 3.2V | 650mAh | 13A | 4.5±0.2 | 34.5±1.0 | 62±1.0 | 17.0±1.5 |
GRP5743058 | 20C | 3.2V | 1000mAh | 20A | 5.4±0.2 | 43±1.0 | 59.5±1.0 | 24.5±1.5 |
GRP5933070 | 20C | 3.2V | 1000mAh | 20A | 5.7±0.2 | 33±1.0 | 70.5±1.0 | 24.0±1.5 |
GRP4634096 | 20C | 3.2V | 1050mAh | 21A | 4.4±0.2 | 33.5±1.0 | 96±1.0 | 27.0±1.5 |
GRP7035062 | 20C | 3.2V | 1100mAh | 22A | 6.6±0.3 | 34.5±1.0 | 62.5±1.0 | 26.5±1.5 |
GRP5549092 | 20C | 3.2V | 1650mAh | 33A | 5.2±0.2 | 48.5±1.0 | 91.5±1.0 | 42.5±2.0 |
GRP7334096 | 20C | 3.2V | 1800mAh | 36A | 7.1±0.3 | 33.5±1.0 | 96.5±1.0 | 43.0±1.5 |
GRP6364074 | 20C | 3.2V | 2000mAh | 40A | 5.8±0.2 | 63.5±1.0 | 73.5±1.0 | 49.5±2.0 |
GRP8434096 | 20C | 3.2V | 2100mAh | 42A | 8.2±0.3 | 33.5±1.0 | 96.5±1.0 | 49.5±2.0 |
GRP9034096 | 20C | 3.2V | 2300mAh | 46A | 8.7±0.3 | 33.5±1.0 | 97.0±1.0 | 54.0±2.0 |
GRP6260082 | 20C | 3.2V | 2350mAh | 47A | 6.0±0.2 | 60±1.0 | 81±1.0 | 56.0±2.0 |
GRP7349092 | 20C | 3.2V | 2500mAh | 50A | 6.9±0.3 | 48.5±1.0 | 91.5±1.0 | 60.0±2.5 |
GRP8134124 | 20C | 3.2V | 2600mAh | 52A | 7.8±0.3 | 33.5±1.0 | 123.5±1.0 | 62.0±2.0 |
GRP6164096 | 20C | 3.2V | 2800mAh | 56A | 5.8±0.3 | 63±1.0 | 97.0±1.0 | 67.5±2.5 |
GRP7242126 | 20C | 3.2V | 3100mAh | 62A | 6.9±0.3 | 41.5±1.0 | 127.0±1.0 | 73.0±2.5 |
GRP7942121 | 20C | 3.2V | 3300mAh | 66A | 7.6±0.3 | 41.5±1.0 | 121.5±1.0 | 77.0±2.5 |
GRP8370090 | 20C | 3.2V | 4000mAh | 80A | 8.0±0.3 | 69.5±1.0 | 89.5±1.0 | 97.0±3.0 |
GRP7867100 | 20C | 3.2V | 4100mAh | 82A | 7.5±0.3 | 66.5±1.0 | 99.5±1.0 | 98.5±3.0 |
GRP7767100 | 20C | 3.2V | 4100mAh | 82A | 7.6±0.3 | 66.5±1.0 | 100.0±1.0 | 101.5±3.0 |
GRP6870135 | 20C | 3.2V | 5000mAh | 100A | 6.5±0.2 | 69±1.0 | 135.5±1.0 | 119.0±3.0 |
GRP5978160 | 20C | 3.2V | 5150mAh | 103A | 5.7±0.2 | 77.0±1.0 | 159.0±1.0 | 130.0±3.0 |
GRP7672125 | 20C | 3.2V | 5500mAh | 110A | 7.3±0.3 | 71±1.0 | 124.5±1.0 | 128.5±3.0 |
GRP8397094 | 20C | 3.2V | 5600mAh | 112A | 8.0±0.3 | 96.5±1.0 | 93.5±1.0 | 135.5±3.0 |
GRP9076119 | 20C | 3.2V | 6400mAh | 128A | 8.6±0.3 | 75±1.0 | 117±1.0 | 148.0±3.0 |
GRP8976119 | 20C | 3.2V | 6400mAh | 128A | 8.6±0.3 | 75±1.0 | 117±1.0 | 152.5±3.0 |
GRPA570145 | 20C | 3.2V | 8400mAh | 84A | 10.2±0.3 | 69.5±1.0 | 144.0±1.0 | 200.0±3.0 |
GRP89C0270 | 20C | 3.2V | 22000mAh | 220A | 8.6±0.3 | 119.0±1.0 | 269.0±1.0 | 520.0±10.0 |
● High performance in power, discharge, and life cycles due to stacking process.
● Ability to achieve 150C pulse, 90C discharge for 2 seconds, 45C continuous discharge, and 5C fast charging.
● Provides better temperature stability and tolerance due to the allowance of higher discharge rate.
● Ultra-thin characteristics, light weight, flexible size, flexible shapes, and ability to accommodate many applications.
Different C Rate Discharge Curve (Nominal Capacity: 1600mAh)
The testing battery nominal capacity is 1600mAh, from the discharge curve under different discharge C rate, we can find the 25C performance is the best, but from 30C to 40C discharge rate, the Grepow LiFePO4 high C rate battery still can provide more than 93% discharge efficiency. | Cycle Life Testing Curve (1C Charging)
Under charging at 1C and discharging at 25C, the high C rate LiFePO4 cell performs an outstanding cycle life performance. From the sheet, we can get there is more than 94% capacity retention rate after 300 cycles. |
Compared with high rate lithium polymer batteries, Grepow high rate lithium iron phosphate batteries use an innovative chemical formulation that provides safe and stable discharge performance; its cycle life is up to 2,000 cycles and can work normally in high temperature environments up to 60°C. Grepow provides integrated battery system customization service of high rate LiFePO4 battery cell customization + battery management system (BMS) + structure design. We can also customize high rate LiFePO4 batteries for different industries according to the actual needs of users, so that your products have greater competitive ability.
▶Battery is more environmental friendly;
▶Stable performance;
▶Safer chemical substance;
▶Support 25C multiplier continuous discharge;
▶Longer life span, more than 2000 cycles;
▶Can work normally in high temperature environment, can withstand 60℃;
▶Perfect service system: Quickly reply to customers' problems and provide solutions
▶Instant local customer support in China, USA, Germany
● Flexible support for customized solutions
● Reliable and stable performance
● Samples and mass production available
● OEM, ODM available
The high C rate LiFePO4 batteries developed and produced by GREPOW are widely used in emergency starter power, car jumper, ups, electric bone drill, electric forklift, electric go-kart, electric lift bed, electric paraglider, industrial robot, high performance racing car, sports equipment starter power, etc. Our R&D team works closely with our customers to provide the right solution for their battery applications.
